ABOUT THESE OPERATING INSTRUCTIONS 1
8011325/18IM/2020-07-02|SICK
Subject to change without notice
OPERATING INSTRUCTIONS | ICR880/890
The simplified designations for system components outlined below are used in the
document with the exception of text passages in which it is necessary to make a clear
distinction between variants.
ICR88x or ICR89x camera system
ICD88x or ICD89x image capture device
ICI890 image capture illumination
MSC800 modular system controller
SIC2000 Sensor Integration Cabinet
SICK Open Portal for Application and
Systems Engineering Tool
SOPAS-ET configuration software
1D codes generally designate bar codes, also referred to as “linear codes”. 2D codes
generally designate stacked codes and matrix codes.
Chapter 9 Technical data lists the types of codes that can be decoded by the camera
system.
