3.7.3 Readable Bar Codes
If your application is known, you may select those known symbologies only to increase the reading speed and
decrease the possibility of reading error. Furthermore, adding the “Symbology ID” into the transmitted data is
also helpful to identify the specific symbology.
PROGRAM
F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
Readable Symbology
SS Auto  00
CS Popular 1D CO
CS Code 128 * 01
CS GS1-128 31
CS UPC-A 02
CS UPC-E * 03
CS EAN-13 * 04
CS EAN-8 * 05
CS Codabar/NW-7 * 06
CS Code 39 * 07
CS Trioptic Code 39 47
CS Standard/Industrial 2 of 5 08
CS Matrix 2 of 5 38
CS Interleaved 2 of 5 * 48
CS China Postal Code 58
CS Germany Postal Code 68
CS Code 93 * 09
CS Code 11 10
CS MSI/Plessey 11
CS UK/Plessey 12
CS Telepen 13
CS GS1 DataBar (RSS-14) * 14
CS IATA 15
CS Coupon Code 16
CS PDF417 * /Micro PDF417 17
CS Codablock F 18
CS Code 16K 19
CS Code 49 20
CS Korea Post Code 21
Remember to scan
“FIN“ after you
terminate this section
(Cycling Scan).
If you choose “Auto”
(Single Scan) you
don’t need to scan
“FIN”.
