91.1 尺寸图
6
1
2
7
8
27
(1.06)
max. 32
(1.26)
14
(0.55)
6.5
(0.26)
10.5
(0.41)
14
(0.55)
15.5
(0.61)
70 (2.76)
M5
6.2
(0.24)
30 (1.18)
92 (3.62)
5
(0.20)
3
4
5
6
15
(0.59)
26
(1.02)
61 (2.40)
14,4
(0.57)
8
插图 56: 尺寸图
1
瞄准槽
2
黄色 LED 指示灯
3
待测物体的优选方向
4
光轴中心 / 发射器
5
光轴中心 / 接收器处于近区
6
光轴中心 / 接收器处于远区
7
贯通孔 ø 5.5 mm,两端适用六角螺母 M5
8
M16 螺纹连接或插头,可旋转 90°
数据 91
8009202.11O1 | SICK
Subject to change without notice
103
