SICK W34 Series User Manual

表 73: DC
H
D
3
NPN
PNP
4
H、PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D、PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
H、NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D、NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
97.2 WT34-Rxxx
U
B
20 V ... 250 V AC/DC: 参照 "技術仕様", ページ 116
表 74: AC/DC
WT34-R2x0
1
L1 / +
2
N / -
3
リレー
4
リレー
5
リレー
1 2 3 4 5
0.14 ... 1.5 mm
2
I
N
= 4 A
97 電気的設置
110
8009202.11O1 | SICK
