SICK W34 Series User Manual

Tabla 53: CC
H
D
3
NPN
PNP
4
H, PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D, PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
H, NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D, NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
71.2 WT34-Rxxx
U
B
20 V ... 250 V CA/CC, véase "Datos técnicos", página 87
Tabla 54: CA/CC
WT34-R2x0
1 L1 / +
2 N / -
3 Relé
4 Relé
5 Relé
1 2 3 4 5
0,14 ... 1,5 mm
2
I
N
= 4 A
INSTALACIÓN ELÉCTRICA 71
8009202.11O1 | SICK
