SICK W34 Series - WT34-Rxxx

Tabelle 13: DC
H
D
3
NPN
PNP
4
H, PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D, PNP: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
H, NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
D, NPN: Q/Q (≤ 100 mA)
+ (L+)
Q/Q
– (M)
+ (L+)
Q/Q
– (M)
19.2 WT34-Rxxx
U
B
20 V ... 250 V AC/DC, siehe "Technische Daten", Seite 28
Tabelle 14: AC/DC
WT34-R2x0
1 L1 / +
2 N / -
3 Relais
4 Relais
5 Relais
1 2 3 4 5
0.14 ... 1.5 mm
2
I
N
= 4 A
19 ELEKTRISCHE INSTALLATION
22
