Table 5: AC/DC relay
Relay
3
WT34-R2x0
H
3
4
5
3
4
5
I
max.
= 4 A @ 250 V AC
4 A @ 24 V DC
0.125 A @ 250 V DC
UL: 4A @ 250 V AC, general
use
4A @ 250 V AC, resistive
(NO)
3A @ 250 V AC, resistive
(NC)
4A @ 24 V DC, NO, general
use
3A @ 24 V DC, NC, general
use
R300
B300 (NO contacts only)
D
3
4
5
3
4
5
7 Additional functions
Alarm
Alarm output: the sensor (WT34-Vxxx) features a pre-failure notification output (“Alarm”
in connection diagram [see "WT34-Bxxx, WT34-Vxxx", page 7]), which issues a notifica‐
tion if the sensor is only ready for operation to a limited extent. The LED indicator
flashes in this case. Possible causes: sensor is contaminated, sensor is out of align‐
ment. In the good state: LOW (0), if excessively contaminated HIGH (1).
Table 6: Alarm
Alarm ( 100 mA)
+ (L+)
Alarm
– (M)
+ (L+)
Alarm
– (M)
ADDITIONAL FUNCTIONS 7
8009202.11O1 | SICK
Subject to change without notice
9
