1 General safety notes
1.1 Safety notes
Read the operating instructions before commissioning.
Connection, mounting, and setting may only be performed by skilled per‐
son.
2006/42/EC
NO
SAFETY
Not a safety component in accordance with the EU Machinery Directive.
When commissioning, protect the device from moisture and contamination.
These operating instructions contain information required during the life cycle of
the sensor.
2 Notes on UL approval
The device must be supplied by a Class 2 source of supply.
UL Environmental Rating: Enclosure type 1
3 Correct use
The WT34 is an opto-electronic photoelectric proximity sensor (referred to as "sensor" in
the following) for the optical, non-contact detection of objects, animals, and persons. If
the product is used for any other purpose or modified in any way, any warranty claim
against SICK AG shall become void.
4 Operating elements and status indicators
Photoelectric proximity sensor with background suppression.
Table 1: Display and operating elements
WT34-Bx2x, -Vx2x, -Bx5x, -
Vx5x
t
2
t
2
t
1
t
1
t
1
+ t
2
t
0
PNP
NPN
D
H
1
2
3
6
4
5
7
1.0
1
Yellow LED indicator
WT34-Bx1x, -Vx1x, -Bx4x, -
Vx4x
PNP
NPN
D
H
1.0
1
2
3
4
1
Yellow LED indicator
WT34-Rx2x, -Rx5x
t
2
t
2
t
1
t
1
t
1
+ t
2
t
0
D
H
1.0
1
2
3
5
4
6
1
Yellow LED indicator
WT34-Rx1x, -Rx4x
D
H
1.0
1
2
3
1
Yellow LED indicator
GENERAL SAFETY NOTES 1
8009202.11O1 | SICK
Subject to change without notice
5
