7SR220 Technical Manual
Chapter 4 - Page 76 of 96 © 2017 Siemens Protection Devices Limited
Binary Output Status Points
Static (Steady-State) Object Number: 10
Change Event Object Number: 11
Control Relay Output Blocks (CROB) Object Number: 12
Binary Output Command Event Object Number: 13
Static Variation reported when variation 0 requested: 1 (Binary Output w/o status)
or 2 (Binary Output with status)
Change Event Variation reported when variation 0 requested: 1 (Binary Output Event w/o Time)
or 2 (Binary Output Event with Time)
Command Event Variation reported when variation 0 requested: 1 (Command Status w/o Time)
or 2 (Command Status with Time)
Point
Index
Description
Default
Change
Event
Assigned
Class
(1, 2, 3
or none)
Default
Variation
Static
Object 10
Default
Variation
Event
Object 11
Default
Command
Event
Object 13
Assigned
Class
(1, 2, 3
or none)
Default
Variation
Command
Event
Object 13
CROB
Supported
Operations
Default
CROB
Operations
103 User SP Command 5. 0 2 2 0 1
Pulse On
Latch On
Close
Pulse On
104 User SP Command 6. 0 2 2 0 1
Pulse On
Pulse OnLatch On
Close
Pulse On
105 User SP Command 7. 0 2 2 0 1 Latch On Pulse On
Close
106 User SP Command 8. 0 2 2 0 1
Pulse On
Pulse OnLatch On
Close
Pulse On
Pulse Off
107 User DP Command 1. 0 2 2 0 1
Latch Off
Pulse Off
Close
Trip
108 User DP Command 2. 0 2 2 0 1
Pulse On
Pulse Off
Latch On
Latch Off
Close
Trip
Pulse On
Pulse Off
109 User DP Command 3. 0 2 2 0 1
Pulse On
Pulse On
Pulse Off
Pulse Off
Latch Off
Close
Trip
Pulse On
Pulse Off
110 User DP Command 4. 0 2 2 0 1
Latch Off
Pulse Off
Close
Trip
111 User DP Command 5. 0 2 2 0 1
Pulse On
Pulse Off
Latch On
Latch Off
Close
Trip
Pulse On
Pulse Off
112 User DP Command 6. 0 2 2 0 1
Pulse On
Pulse Off
Latch On
Latch Off
Close
Trip
Pulse On
Pulse Off
