Service and maintenance
10.1 Error and diagnostics messages
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
231
Error code
(%c)
Error message
(%s)
Description
4710
Verification failed in step n: Data Matrix ECC200
required
Verification requires a data matrix code according to
ECC200 specification (only for verification according to
ISO/IEC 15415 or ISO/IEC 29158).
4711
Verification failed in step n: Aperture too small
The cell size of the data matrix code in step #n is too
large for the configured aperture (only for verification
according to ISO/IEC 15415).
4712
Verification failed in step n: Aperture too large
The cell size of the data matrix code in step #n is too
small for the configured aperture (only for verification
according to ISO/IEC 15415).
4713
Verification failed in step n: Not enough space
around the Data Matrix
The quiet zone around the data matrix contained in
the image is too small. For verification, a quiet zone of
at least the size of two cells is required (only for verifi-
cation according to ISO/IEC 15415 or 29158).
4714
Verification failed in step n: RDA could not find the
horizontal timing pattern
The reference decoding according to
ISO/IEC 16022:2006 signals an error when searching
for the horizontal timing pattern (only for verification
according to ISO/IEC 15415 or ISO/IEC 29158).
4715
Verification failed in step n: RDA could not find the
vertical timing pattern
The reference decoding according to
ISO/IEC 16022:2006 signals an error when searching
for the vertical timing pattern (only for verification
according to ISO/IEC 15415 or ISO/IEC 29158).
4716
Verification failed in step n: RDA found an incor-
rect number of rows and columns
The reference decoding according to
ISO/IEC 16022:2006 signals an error when determin-
ing the number of rows or columns (only for verifica-
tion according to ISO/IEC 15415 or ISO/IEC 29158).
4717
Verification failed in step n: RDA could not locate
the finder pattern
The reference decoding according to
ISO/IEC 16022:2006 signals an error when searching
for the finder pattern (only for verification according
to ISO/IEC 15415 or ISO/IEC 29158).
4719
Verification failed in step n: RDA error correction
failed
The reference decoding according to
ISO/IEC 16022:2006 signals an error when determin-
ing the error correction (only for verification according
to ISO/IEC 15415 or ISO/IEC 29158).
4720
Verification failed in step n: Number of Data Ma-
trix rows/columns is too high
The maximum supported code size for verification
according to ISO/IEC 15415 or ISO/IEC 29158 is
104x104 cells.
4721
Verification failed in step n: Cell size is smaller
than the specified Min.X Dim.
During verification, a cell size was measured that is
less than the minimum X-dimension setting (only for
verification according to ISO/IEC 29158).
4722
Verification failed in step n: Cell size is larger than
the specified Max.X Dim.
During verification, a cell size was measured that is
greater than the maximum X-dimension setting (only
for verification according to ISO/IEC 29158).
5000
Not enough resources to process step n
Step #n could not be executed due to a lack of re-
sources (memory).
5001
No objects found in step n
Locator: No objects were found in step #n.
5001
No objects found in step n
Locator: No objects were found in step #n.
5002
Too few objects found in step n
Locator: The number of objects found in step #n is
lower than the set minimum.
5003
Too few objects found in step n: Required feature
is missing
Locator: The number of objects found in step #n is
lower than the set minimum. At least one object was
rejected because of a missing required feature.
