Service and maintenance
10.1 Error and diagnostics messages
SIMATIC MV500
232 Operating Instructions, 03/2021, C79000-G8976-C494-05
Error code
(%c)
Error message
(%s)
Description
5004
Too few objects found in step n: Rotation range
exceeded
Locator: The number of objects found in step #n is
lower than the set minimum. At least one object was
rejected because it did not comply with the rotation
constraint.
5005
Too few objects found in step n: Scaling range
exceeded
Locator: The number of objects found in step #n is
lower than the set minimum. At least one object was
rejected because it did not comply with the scale con-
straint.
5006
Too few objects found in step n: Contours not
adequate
Locator: The number of objects found in step #n is
lower than the set minimum. At least one object was
rejected because insufficient contours were found.
5008
Too few objects found in step n: Details not rec-
ognized
Locator: The number of objects found in step #n is
lower than the set minimum. At least one object that
was identified at the outline level was rejected at the
detail level.
5009
Too few objects found in step n: Outline not rec-
ognized
Locator: The number of objects found in step #n is
lower than the set minimum. No object was found at
the outline level.
5010
Too few objects found in step n: Clear percentage
violated
Locator: The number of objects found in step #n is
lower than the set minimum. At least one object was
rejected because it did not comply with the clear per-
centage constraint.
5011
Too many objects found in step n
Locator: The number of objects found in step #n is
higher than the set maximum.
5012
Quality too poor in step n
Locator: The objects found in step #n are below the set
quality threshold.
5013
Average Quality too poor in step n
Locator: The objects found in step #n are below the set
average quality threshold.
5014
Match error tolerance exceeded in step n
Locator: The match performed in step #n was not
successful because the number of match errors was
higher than the maximum number permitted.
5015
Position tolerance exceeded for object m in step n
Locator: The position of object m in step #n is outside
the maximum permitted deviation.
5016
Rotation tolerance exceeded for object m in step n
Locator: The rotation angle of object m in step #n is
outside the maximum permitted deviation.
5017
Too few objects found in step n: Alignment failed
Locator: The number of objects found in step #n is
smaller than the set minimum. At least one object was
filtered out through the "Alignment".
