Appendix
A.3 Alternative user interfaces
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
281
Overview of available URLs
The following URLs provide access to the pages described below in their respective language.
Access via an unencrypted connection (http) is only possible for the following pages when
user management is active.
• Example URL for the page "Live Image with links" in the English user interface:
http://<IP address of the optical reader>/peeklive.html
• Example URL for the encrypted page "Live Image with links" in the English user interface:
https://<IP address of the optical reader>/peeklive.html
Overview of the HTML pages for monitoring the optical reader
Table A- 2 English, Chinese, German
Page
English
Chinese
German
Homepage
1)
index_en.html
index_zh.html
index_de.html
Setup (user interface)
1)
adj_en.cgi
adj_zh.cgi
adj_de.cgi
Diagnostic recordings
2)
diagrecs.cgi?rg=65535
diagrecs.cgi?rg=65535
diagrecs.cgi?rg=65535
Diagnostic images
2)
diagimgs.cgi?tn=1
diagimgs.cgi?tn=1
diagimgs.cgi?tn=1
Extended diagnostic images
2)
ediagimghtml.cgi
ediagimghtml.cgi
ediagimghtml.cgi
Live Image with links
peeklive.html
peeklive_zh.html
peeklive_de.html
Live image without links
2)
epeeklive.html
epeeklive.html
epeeklive.html
Last image
2)
live.cgi?d=0
(d=0: not-down sampled,
d=1 down sampled)
live.cgi?d=0
(d=0: not-down sampled,
d=1 down sampled)
live.cgi?d=0
(d=0: not-down sampled,
d=1 down sampled)
Monitoring
2)
drawresults.cgi
drawresults.cgi
drawresults.cgi
Verification report
cgui/verifireport_en.html
cgui/verifireport_en.html
cgui/verifireport_de.html
1)
The language in which the HTML page is displayed is independent of the language abbreviation used. The HTML pages
are always displayed in the language set in the WBM.
2)
These HTML pages are displayed only in English.
