A.3 Alternative user interfaces
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
287
Navigation is made easier by the large area navigation symbols at the left edge.
Figure A-7 Extended diagnostic images (optimized for Touch Panels)
Diagnostic recordings
Provides a dynamically created HTML page with which you can display diagnostic recordings
buffered on the optical reader relating to errors that occurred, signal changes etc.
Figure A-8 Diagnostic recordings
