Infrared Link Modul (ILM)
6ZB530–3AC30–0BA1
34
Copyright  by Siemens
ILM
ILM
Direction of emission
Installation of the ILM with mounting bracket
top view
Washer
Two toothed washers
Bolt M6 x 16
Nut M6
Washer
Alignment by installing in other holes
Mounting bracket 2
Secured on
base with two M4
bolts
Mounting bracket 1
Figure 14: Top View of the PROFIBUS ILM Installed With Mounting Brackets
