Siemens SIMATIC NET PROFIBUS User Manual

Infrared Link Modul (ILM)6ZB5530–3AC30–0BA1
33
Copyright  by Siemens
The finished construction of the support with two mounting angles and the securing of the PROFIBUS ILM is
described in Figures 13 to 15.
SIEMENS PROFIBUS ILM
Installation of the ILM with a mounting bracket
front view
Site of in-
stallation
Mounting
bracket 2
Secured to a
base with two
bolts
Toothed washer
Bolt
M 6x16
Nut M6
Washer
Mounting bracket 1
Figure 13: Front View of the PROFIBUS ILM Installed with Mounting Brackets
