Description of the views
3
3.1 vAction
User actions
User actions are shown here. User actions are those actions initiated by the user on a batch
or batch elements.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
P2OBJID int ID of the higher-level object of the con‐
tainer object
P2OTID (Page 60) int ID of the higher-level object of the con‐
tainer object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
ActivationCounter Int Run of the object
OBJID Int ID of the action
OTID (Page 60) Int Type of the action
ActionType (Page 53) Int Action
State (Page 53) Int Status of the action
EsigDynDataId Int ID of EsigDynData (*)
Userlogin nvarchar(255) Login
Userloginlong nvarchar(255) Processor
CreationTimestamp datetimeoffset(3) Creation date of the action
CreationHostname nvarchar(255) Original computer of the action
ExecutionTimestamp datetimeoffset(3) Execution date of the action
ExecutionHostName nvarchar(255) Execution computer of the action
*: (action.ROOTGUID = executedesig.ROOTGUID, action.POBJID= executedesig.POBJID,
action.POTID= executedesig.POTID, action.P2OBJID= executedesig.P2OBJID,
action.P2OTID= executedesig.P2OTID, action.EsigDynDataId =
executedesig.EsigDynDataId)
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 11
