Name Data type Description
Name nvarchar(255) Name of the material
Code nvarchar(16) Code of the material
Withdrawn Bit Material has been deleted
Description nvarchar(max) Description of the material
InputMaterial Bit Input material
OutputMaterial Bit Output material
3.21 vMessageExtended
Batch messages
Extended view of the batch messages.
In contrast to "vCDVMessage", the linking of objects with the messages is simplified, allowing
you to link them as in the standard scheme. See Linking objects with their properties.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
P2OBJID Int ID of the higher-level object of the con‐
tainer object
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
TimeStamp datetimeoffset (3) Time stamp of the message
OS_Server nvarchar(255) Origin of the OS message
MsgNumber Bigint WinCC message number
MsgCounter Bigit Consecutive number (OS-specific) as‐
signed by WinCC
MsgType Int 1: Status message
2: Operator message
3: Error message
4: Limit violation message
ClassId (Page 56) Int WinCC message class
TypeId (Page 60) Int WinCC message type
State (Page 60) Int Status of the WinCC message (incom‐
ing, outgoing, etc.)
UserName nvarchar(256) Operator name
Description of the views
3.21 vMessageExtended
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 25
