Name Data type Description
UserOperation nvarchar(256) Operator text with operator name and
type ID of the reporting object
Origin nvarchar(256) Name of the reporting object
Message nvarchar(256) Message in text form
Area nvarchar(256) Name of the unit. Only for messages
within a recipe unit.
3.22 vMonitoredObjects
Monitored objects
View of the objects which are tracked by the monitor. The (1:n) link of the vMonitor views
(vContainer, vRecipeElement) to this view is based on the columns ROOTGUID, POBJID,
POTID, OBJID, OTID.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master
recipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) InI Type ID of the root object
POBJID Int ID of the higher-level object of the mon‐
itoring
POTID (Page 60) Int Type ID of the higher-level object of the
monitoring
OBJID Int ID of the monitoring
OTID (Page 60) Int Type ID of the monitoring object
MonitoredStepNo Int Number of the monitored object (con‐
tid*10000+termid)
MonitoredStepPath nvarchar(512) Hierarchical path of the monitored object
3.23 vMonitor
Monitoring
This view shows the available monitoring. It is a specialization of the vContainer view.
Description of the views
3.22 vMonitoredObjects
SIMATIC BATCH - Views of the report data V9.0
26 Programming Manual, 05/2017, A5E38208785-AA
