5.14 Level
ID Description
1 Process cell
2 Unit
3 Equipment module
4 Equipment procedure
5 Equipment unit procedure
6 Equipment operation
7 Equipment phase
8 Collection of actual values in the process cell with TAG_COLLECT (collection of equipment tags)
5.15 MessageState
ID Description
1 Incoming
2 Outgoing
3 Acknowledged
4 Locked
10 Hidden
11 Displayed
16 System acknowledged
17 Not acknowledged
5.16 MessageType
ID Description
1 Messages
2 Operator messages
3 Error messages
4 Limit violations
5.17 ObjectType
ID Description
3 Batch
4 Possible unit (candidate)
5 Condition
Description of the enumerations
5.14 Level
SIMATIC BATCH - Views of the report data V9.0
60 Programming Manual, 05/2017, A5E38208785-AA
