Name Data type Description
ActStart datetimeoffset(3) Actual start time of the batch
ActEnd datetimeoffset(3) Actual end time of the batch
StartMode (Page 64) Int Start mode of the batch
State (Page 55) Int (*) Status of the batch
ExState (Page 55) Int (*) Extended status of the batch
PCellGUID Uniqueidentifier GUID of the BATCH process cell (PCell)
CreationDateTime Datetimeoffset(3) Creation date of the object
ModificationDateTime Datetimeoffset(3) Date of the last change
BatchVersion nvarchar(255) SIMATIC BATCH version
3.5 vBatchArchive
Archived batches
View of archived batches. This data is relevant only if you have archived batches in the
database of a Process Historian.
Definition
Name Data type Description
AutoValueID Int Internal ID
BatchGUID Uniqueidentifier GUID of the batch
BatchName Int Name of the batch
BatchID Int Batch ID
BatchDescription nvarchar(max) Batch
BatchVersion nvarchar(32) Version of the software
BatchStartTime datetimeoffset(3) Start time of the batch
BatchEndTime datetimeoffset(3) End time of the batch
RuntimeDBIdent nvarchar(64) DBIdent
PCS7ProjectName nvarchar(256) Project name
PCellName nvarchar(256) Name of the process cell
ProductName nvarchar(256) Name of the product
MasterRecipeName nvarchar(256) Name of the master recipe
MasterRecipeVersion nvarchar(32) Version of the master recipe
FormulaName nvarchar(256) Name of the formula
FormulaVersion nvarchar(32) Version of the formula
FormulaCategoryName nvarchar(256) Name of the formula category
OrderName nvarchar(256) Name of the order
OrderCategoryName nvarchar(256) Name of the order category
ArchiveVersion nvarchar(32) Version of the XML
Description of the views
3.5 vBatchArchive
SIMATIC BATCH - Views of the report data V9.0
14 Programming Manual, 05/2017, A5E38208785-AA
