Name Data type Description
Description nvarchar(max) Description of the object
ModificationDateTime datetimeoffset (3) Last change date of the object
3.19 vInstance
Process cell instances
View of all process cell instances (PCell, Unit, EMOD, EP, EUP, EOP, EPH, TagCollect).
Definition
Name Data type Description
PCellGUID Unique identifier GUI of the process cell object
PCellPartID Int Part ID of the process cell object
POBJID Int Instance ID of the higher-level object
OBJID Int ID of the instance
Name nvarchar(255) Name of the instance
Description nvarchar(max) Description of the instance
RTName nvarchar(255) Runtime name of the instance
VersionNr Int Name of the block
Level (8) TinyInt Level of the equipment
Category Int ID of the category of the object from the
vCategory view
3.20 vMaterial
Materials used
The view shows all materials for each transmitted object. These are process cells and batch
objects. The materials at the time of the printout or archiving of the batch are listed.
Definition
Name Data type Description
OGUID Uniqueidentifier GUID of the object
OBJID Int ID of the object
Version Int The version of the material always as‐
sumes the value 1 on the local SQL
server. If the material is changed in the
BatchCC, the version of a material is al‐
ways incremented by 1 on a PH.
Description of the views
3.19 vInstance
SIMATIC BATCH - Views of the report data V9.0
24 Programming Manual, 05/2017, A5E38208785-AA
