Name Data type Description
ArchiveTimeStamp datetimeoffset(3)
ArchiveDataType nvarchar(32) XML or PDF
ArchiveData varbinary(max)
3.6 vCategory
Phase and process tag types
View of all phase and process tag types from PCS 7 Engineering.
Definition
Name Data type Description
PCellGUID Unique identifier GUID of the process cell object
PCellPartID Int Part ID of the process cell object
ID Int ID of the object
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
3.7 vCDVMessage
Messages of the batches
This view contains the messages of the batches.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
P2OBJID Int ID of the higher-level object of the con‐
tainer object
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
TimeStamp datetimeoffset (3) Time stamp of the message
Description of the views
3.6 vCategory
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 15
