Name Data type Description
TimeStamp Datetimeoff‐
set(3)
Time stamp of the status change. Exclusively as UTC time
stamp.
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object (batch or recipe element)
StepNo Int Step number of the object (ContId*10000+TermId) or for tech‐
nical functions in manual operation, the EPH-ID
State Int Status of the object after the status change
ExState Int Extended status of the object after the status change
OldState Int Status of the object before the status change
OldExState Int Extended status of the object before the status change
UnitID Int ID of unit
AllocID Int ID of the allocation (UnitAlloc)
ROPActivationCounter Int Run number of the active recipe operation. If no ROP is active,
"NULL" is returned here.
RUPActivationCounter Int Run number of the unit recipe. This value is always present in
hierarchical batches. "NULL" is returned in flat batches.
3.42 vSUB
Substructures
This view shows the available substructures. It is a specialization of the vContainer view.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master rec‐
ipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
POBJID Int ID of the higher-level object
POTID (Page 60) Int Type ID of the higher-level object
ParentActivationCounter Int Run of the parent of the object
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
ActivationCounter Int Run of the object
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
State (Page 62) Int Status of the container
ExState (Page 63) Int Expanded status of the container
Description of the views
3.42 vSUB
SIMATIC BATCH - Views of the report data V9.0
44 Programming Manual, 05/2017, A5E38208785-AA
