Name Data type Description
ArchiveName nvarchar(255) Name of the archive (system archive,
etc.)
TagName nvarchar(255) Name of variables
TagPath nvarchar(max) Runtime path of the process tag
MinTagValue
(1)
Float Minimum value
MaxTagValue
(1)
Float Maximum value
UoMId Int ID of the unit of measurement of the
process tag
UoMName nvarchar(255) Name of the unit of measurement of the
process tag
StartTime datetimeoffset(3) Start time for collecting measured val‐
ues
StopTime datetimeoffset(3) End time for collecting measured values
MaxTagValueNo
(1)
Int Number of collected measured values
TagValueTime datetimeoffset(3) Time of the measured value
TagValue Float Measured value
TagValueQuality Int Quality of the measured value
(1)
The columns are not part of the data in Process Historian and are therefore displayed as
"NULL". This data can be determined later using SQL (min, max, ...).
3.31 vOrder
Orders
This view shows the available orders.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (order category)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
OGUID Uniqueidentifier GUID of the object (order)
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
Name nvarchar(255) Name of the order
CreationDateTime Datetimeoffset(3) Creation date of the object
EarliestDateTime Datetimeoffset(3) Earliest start for the batches
LatestDateTime Datetimeoffset(3) Latest end for the batches
Quantity Float Planned quantity
Description nvarchar(max) Description of the order
Description of the views
3.31 vOrder
SIMATIC BATCH - Views of the report data V9.0
34 Programming Manual, 05/2017, A5E38208785-AA
