Name Data type Description
sp_locname nvarchar(255) Setpoint (location name)
asp_locname nvarchar(255) Actual-setpoint (location name)
av_locname nvarchar(255) Process value (location name)
sp_matname nvarchar(255) Setpoint (material name)
sp_matcode nvarchar(255) Setpoint (material code)
asp_matname nvarchar(255) Actual-setpoint (material name)
asp_matcode nvarchar(255) Actual-setpoint (material code)
av_matname nvarchar(255) Process value (material name)
av_matcode nvarchar(255) Process value (material code)
sp_EnumValue nvarchar(255) Setpoint (name of Enum value)
asp_EnumValue nvarchar(255) Actual-setpoint (name of Enum value)
av_EnumValue nvarchar(255) Process value. Name of the Enum value
sp_Unit nvarchar(255) Setpoint. Name of the unit
asp_Unit nvarchar(255) Actual-setpoint. Name of the unit
av_Unit nvarchar(255) Process value. Name of the unit
sp_prot Int Setpoint: Reserved for user data
asp_prot Int Actual-setpoint: Reserved for user data
av_prot Int Process value: Reserved for user data
3.30 vOnlineTagExtended
Extended view of the measured values of the batches
In contrast to the "vOnlineTag" view, the linking of objects with the measured values is
simplified, allowing you to link them as in the standard scheme. See Linking objects with their
properties.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch)
ROOTOTID (Page 60) Int Type ID of the root object
ROOTOBJID Int ID of the root object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
P2OBJID Int ID of the higher-level object of the con‐
tainer object
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
OBJID Int ID of the process tag
ActivationCounter Int Run of the object
BatchName nvarchar(255) Name of the batch
Description of the views
3.30 vOnlineTagExtended
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 33
