3.29 vOnlineParameterValue
Parameter data of the batches
This view contains the parameter data of the batches. Only parameters of the batches and the
recipe elements that have already been started (only the last parameter set per run) are
provided.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object
P2OBJID Int ID of the higher-level object of the con‐
tainer object
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
ActivationCounter Int Run of the parent of the object
OBJID Int ID of the parameter
DataID Bigint Unique ID of the notification for the pa‐
rameter set to which this parameter val‐
ue belongs.
Name nvarchar(255) Name of parameter
UsageID (Page 66) Int Type of parameter
DataTypeID Int ID of the data type
DataTypeName nvarchar(255) Name of the data type
UoMID Int ID of the technical unit of measure
UoMName nvarchar(255) Name of the technical unit of measure
HighValue Float High limit of the value
LowValue Float Low limit of the value
RecHighValue Float High limit of the recipe
RecLowValue Float Low limit of the recipe
sp_float Float Setpoint (float)
asp_float Float Actual-setpoint (float)
av_float Float Process value (float)
sp_int Int Setpoint (int)
asp_int Int Actual-setpoint (int)
av_int Int Process value (int)
sp_string nvarchar(255) Setpoint (string)
asp_string nvarchar(255) Actual-setpoint (string)
av_string nvarchar(255) Process value (string)
loc_unitallocname nvarchar(255) Assignment name of the transfer param‐
eter
loc_unitname nvarchar(255) Unit name of the transfer parameter
Description of the views
3.29 vOnlineParameterValue
SIMATIC BATCH - Views of the report data V9.0
32 Programming Manual, 05/2017, A5E38208785-AA
