4.2 batch_GetStandardReport
Transition parameter
1. @lcid (integer): Language ID (1031: German, 1033: English, etc.)
2. @batchguid (Unique identifier): GUID of the batch.
This function returns the data that is displayed in the main report of a batch. There are two
types of data in the returned data records:
● ELEM (TYPEID: 0): These are elements of the batch (batch and recipe elements). The
elements are sorted by start time and hierarchy. The RSOid column of hierarchyid type
determines the order.
● SUBELEM (TYPEID: 10): The sub-elements of an element are displayed under the same
section as the container element.
Definition
Name Data type Description
ORDINAL Int Number of the element. Determines the order of the elements.
RSO Nvarchar(255) Grouping number in the report
RSOid Hierarchyid Grouping number in the report
TYPEID Int Type of data record (0: ELEM, 10: SUBELEM, 11: STATE‐
CHANGE)
OBJID Int ID of the object
OTID Int Type ID of the object
POBJID Int ID of the container object
POTID Int Type ID of the container object
ActivationCounter Int Run of the object
Name Nvarchar(255) Name of the object
StepNo Int Number of the object (contid*10000+termid)
Description Nvarchar(max) Description of the object
DataDescription Nvarchar(max) Description of the function from the engineering
OPDActiv (11) Int Activation status of the operator dialog
StepCommand (13) Int Command to be executed
ScaleFunc Int Modification of the duration
ParameterSequence Nvarchar(max) Sequence of the parameters in CSV format (e.g.: ";1;4;2;5;3")
CatID Int Category ID of the object
PCellGUID4Category Uniqueidentifier GUID of the PCell to which the category of the element belongs
Path nvarchar(255) Hierarchical path to the object
Level Int Level of the object
ProcModel Int Recipe model (2:Flat, 1:Hierarchical)
SOT (32) Int Extended type of the object
Description of the table value functions
4.2 batch_GetStandardReport
SIMATIC BATCH - Views of the report data V9.0
50 Programming Manual, 05/2017, A5E38208785-AA
