Name Data type Description
HiValue_int Int High limit of the value
RecLoValue_int Int Low recipe limit of the value
RecHiValue_int Int High recipe limit of the value
Value_int Int Formula for calculating the value
LoValue_float float Low limit of the value
HiValue_float float High limit of the value
RecLoValue_float float High recipe limit of the value
RecHiValue_float float High recipe limit of the value
Value_float float Value (float)
Value_string nvarchar(max) Value (string)
Mat_SpMatGUID uniqueidentifier GUID of the material
Mat_SpMatID Int ID of the material
FormulaOrProcedureGUID uniqueidentifier GUID of the category of the higher-level object
FormulaOrProcedureId Int ID of the category of the higher-level object
AllocId Int ID of the occupation
SpTransferUnitID Int ID of unit (with transfer parameter)
SpProt Int Setpoint:
Reserved for user data
ActProt Int Process value:
Reserved for user data
3.27 vOfflineTag
Configured process tags
This view contains the configured process tags.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master
recipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
OBJID Int ID of the container object
Name nvarchar(255) Name of the process tag
Description nvarchar(max) Description of the process tag
P2OBJID Int ID of the higher-level object of the con‐
tainer object
Description of the views
3.27 vOfflineTag
SIMATIC BATCH - Views of the report data V9.0
30 Programming Manual, 05/2017, A5E38208785-AA
