3.44 vTermTrans
Terminals and transitions
This view shows the available terminals (RF, command step, equipment operation, operator
instruction, library reference) and transitions. It is a specialization of the vRecipeElement view.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master rec‐
ipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
POBJID Int ID of the higher-level object
POTID (1) Int Type ID of the higher-level object
ParentActivationCounter Int Run of the parent of the object
OBJID Int ID of the object
OTID (1) Int Type ID of the object
ActivationCounter Int Run of the object
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
State (Page 62) Int Status of the container
ExState (Page 63) Int Expanded status of the container
Start datetimeoffset(3) Start time of the container
End datetimeoffset(3) End time of the container
DurationPlanned Int Planned duration in seconds
DurationActual Int Actual duration in seconds
DataDescription nvarchar(max) Runtime path of the function
MonitoringTime Int Monitoring time in seconds
OverwriteDuration Int The runtime calculated by the system can
be changed or overwritten
ScaleFunc (Page 64) Int Modification of the duration
UnitRel Bit Unit is released at the end
AllocId Int ID of the allocation
UnitId Int ID of unit
UnitName nvarchar(255) Name of the unit. Only relevant for flat rec‐
ipes.
CategoryGUID Uniqueidentifier GUID of the library, if it is a library reference
OPDActiv (Page 62) tinyint Activation status of the operator instruction
OPDIsQuit (Page 62) tinyint Status of the acknowledgment
ContinousFlag Bit Continue
ExecuteInPLC Bit Executed in AS-based mode
Description of the views
3.44 vTermTrans
SIMATIC BATCH - Views of the report data V9.0
46 Programming Manual, 05/2017, A5E38208785-AA
