3.17 vFormula
Formula
This view contains all the created categories.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (formula catego‐
ry)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
OGUID Uniqueidentifier GUID of the object (formula)
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
Name nvarchar(255) Name of the batch
Description nvarchar(max) Description of the object
State (Page 59) Int Status of the formula
AutomaticVersioning Bit System-aided versioning
MajorVersion Int Major version (with system supported
versioning)
MinorVersion Int Minor version (system supported ver‐
sioning)
ProcGUID GUID of the master recipe
PCellGUID GUID of the process cell (PCell)
ProductId ID of the product
ModificationDateTime Datetimeoffset(3) Last change date of the object
3.18 vFormulaCategory
Formula categories
This view contains all of the formula categories.
Definition
Name Data type Description
OGUID Uniqueidentifier GUID of the object (formula category)
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
Name nvarchar(255) Name of the batch
Description of the views
3.17 vFormula
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 23
