Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master rec‐
ipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
POBJID Int ID of the higher-level object
POTID (Page 60) Int Type ID of the higher-level object
ParentActivationCounter Int Run of the parent of the object
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
ActivationCounter Int Run of the object
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
State (Page 62) Int Status of the container
ExState (Page 63) Int Expanded status of the container
Start datetimeoffset(3) Start time of the container
End datetimeoffset(3) End time of the container
DurationPlanned Int Planned duration in seconds
DurationActual Int Actual duration in seconds
MonitoringTime Int Monitoring time in seconds
OverwriteDuration Int The runtime calculated by the system can
be changed or overwritten
ScaleFunc (Page 64) Int Modification of the duration
ExecuteInPLC Int Executed in AS-based mode
GraphicType tinyint Type of stored graphic (1: png)
Graphic varbinary(max) Graphic in BLOB format
3.24 vModification
Changes to objects
This involves the logging of changes made to objects (batch, master recipe, library, formula).
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master
recipe, library, formula)
ROOTOBJID Int ID of the root object
Description of the views
3.24 vModification
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 27
