Name Data type Description
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
State (Page 62) Int Status of the container
ExState (Page 63) Int Expanded status of the container
Start datetimeoffset(3) Start time of the container
End datetimeoffset(3) End time of the container
DurationPlanned Int Planned duration in seconds
DurationActual Int Actual duration in seconds
MonitoringTime Int Monitoring time of the object in seconds
OverwriteDuration Int Runtime calculated by the system. Can
be changed or overwritten.
ScaleFunc (Page 64) Int Modification of the duration
UnitRel Bit Unit is released at the end
AllocId Int ID of the allocation
UnitId Int ID of unit
UnitName Int Name of the unit
ExecuteInPLC Int Executed in AS-based mode
GraphicType tinyint Type of stored graphic (1:png)
Graphic varbinary(max) Graphic in BLOB format
3.39 vRecipeOperation
Recipe operations
This view shows the available recipe operations. It is a specialization of the vContainer view.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master
recipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
POBJID Int ID of the higher-level object
POTID (Page 60) Int Type ID of the higher-level object
ParentActivationCounter Int Run of the parent of the object
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
ActivationCounter Int Run of the object
Name nvarchar(255) Name of the object
Description of the views
3.39 vRecipeOperation
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 41
