Name Data type Description
OS_Server nvarchar(255) Origin of the OS message
MsgNumber bigint WinCC message number
MsgCounter bigit Consecutive number (OS-specific) as‐
signed by WinCC
MsgType Int 1: Status message
2: Operator message
3: Error message
4: Limit violation message
ClassId (Page 56) Int WinCC message class
TypeId (Page 60) Int WinCC message type
State (Page 60) Int Status of the WinCC message (incom‐
ing, outgoing, etc.)
UserName nvarchar(256) Operator name
UserOperation nvarchar(256) Operator text with operator name and
type ID of the reporting object
Origin nvarchar(256) Name of the reporting object
Message nvarchar(256) Message in text form
Area nvarchar(256) Name of the unit. Only for messages
within a recipe unit.
Priority Int Priority of the message
3.8 vChangedItems
Changes
The changes resulting from actions are shown here, for example, changed objects
(parameters) from an "Online parameter change" action.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type of the root object
P3OBJID Int ID of the higher-level object of the con‐
tainer object
P3OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
P2OBJID Int ID of the container object of the action
P2OTID (Page 60) Int Type ID of the container object of the
action
POBJID Int ID of the action
Description of the views
3.8 vChangedItems
SIMATIC BATCH - Views of the report data V9.0
16 Programming Manual, 05/2017, A5E38208785-AA
