Name Data type Description
ActvalProt Int Process value: Reserved for user data
ActValCol Bit Production instruction property activa‐
ted in the engineering.
Withdrawn Bit Object has been deleted
3.34 vParameterRTInfo
Parameter data of the batches
Supplies all setpoints and process values of all parameters that either:
● Are relevant for a status change in the "vStateChange" view
● Have to be changed by the user independently of a status change
● Were supplied by IRefresh
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the batch
P2OBJID Int ID of the higher-level object of the con‐
tainer object
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
ActivationCounter Int Run of the container element
OBJID Int ID of the parameter
TimeStamp Datetimeoffset(3) Time stamp corresponding to the asso‐
ciated event. For example, values for
status change, parameter changes,
reading process values (IRefresh, …) or
manual operation may be available. Ex‐
clusively as UTC time stamp
DataID bigint Reference to the status change. Does
not apply per data record, but to a num‐
ber of data records. This date has a di‐
rect relation to "DataID" in the "vState‐
Change" view – every data record in
"vStateChange" has elements in this
view, but not vice versa.
ChangeType Int Type of change (combination of status
change, write setpoints, read process
values and setpoint change)
Name nvarchar(255) Name of parameter
Usage Int Type of parameter. PI, PO, PP or RP/TP
Description of the views
3.34 vParameterRTInfo
SIMATIC BATCH - Views of the report data V9.0
36 Programming Manual, 05/2017, A5E38208785-AA
