Name Data type Description
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
OBJID Int ID of the error
OTID (Page 60) Int Type ID of the error
EntryType (Page 56) Int Type ID of the object
ErrorClass (Page 59) Int Type of the error
ErrorReason (Page 57) Int Reason for the error
3.16 vExtendedErrorState
Status of extended error messages
This view contains all statuses of the extended error messages of the BATCH server.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
P3OBJID Int ID of the higher-level object of the con‐
tainer object
P3OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
P2OBJID Int ID of the container object of the error
P2OTID (Page 60) Int Type ID of the container object of the
error
POBJID Int ID of the errors
POTID (Page 60) Int Type ID of the error
ActivationCounter Int Run of the object
OBJID Int ID of the error status
OTID (Page 60) Int Type ID of the error status
State (Page 58) Int Status of the error
TimeStamp Datetimeoffset(3) Time stamp for the status change of the
error
ErrorInfo Int Information about the error
Description of the views
3.16 vExtendedErrorState
SIMATIC BATCH - Views of the report data V9.0
22 Programming Manual, 05/2017, A5E38208785-AA
