Name Data type Description
ClosedExamination Bit This means that if more than one signa‐
ture is required, all signatures must be
provided at the same time, in other
words, in an open "Sign" dialog box.
InputOrderRandom Bit Order that must be maintained in provid‐
ing the required signatures
CountOfUserRole Int Number of roles that need to sign
3.26 vOfflineParameterValue
Parameters of the offline objects
View of the offline parameters (parameters of the equations, recipes and batches)
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master recipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
P2OBJID Int ID of the higher-level object of the container object
P2OTID (Page 60) Int ID of the higher-level object of the container object
POBJID Int ID of the higher-level object
POTID (Page 60) Int Type ID of the higher-level object
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
DataTypeID Int ID of the data type
ScalingId Int Adaptation function
ValueSource Int Origin of the setpoint.
1: Local
2: Source interconnected
3: Boolean or arithmetic expression
4: Equipment
ValueDestId Int ID of the target parameter,
ID of the corresponding parameter in the higher-level
object.
ValueSourceId Int ID of the source parameter,
ID of the corresponding parameter in the higher-level
object.
CalcScript nvarchar(max) Formula for calculating the value
LoValue_int Int Low limit of the value
Description of the views
3.26 vOfflineParameterValue
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 29
