ID Description
6 Completing
7 Completed
8 Continuous mode
9 Aborted
10 Aborting
11 Stopped
12 Stopping
13 Held
14 Holding
15 Resuming
16 Paused after step
17 Pausing after step
30 Switched
5.21 RpeExState
Possible additional status expansions of a recipe element.
ID Description
0x00000001 Error
0x00000004 Command is being executed
0x00000008 Breakpoint
0x00000010 Waiting for unit
0x00000020 Unit allocated
0x00000040 Waiting for equipment phase/operation
0x00000080 Equipment phase/operation occupied
0x00000100 Electronic signature required
0x00000200 Open operator dialog/instruction
0x00000400 Write lock
0x00000800 Start lock
0x00001000 Continuous mode
0x00004000 Manual operation
0x00008000 Runtime exceeded
0x00010000 Subobject held or canceled
0x00020000 Subobject waiting
0x00040000 Subobject requires operator action
0x00080000 Child object in error
0x00100000 Equipment error (corresponds to bit 31 at the block)
0x00200000 Allocation error
0x00400000 Pause
0x00800000 Virtual allocation - the unit remains allocated (flat recipe)
Description of the enumerations
5.21 RpeExState
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 63
