Name Data type Description
MsgNumber Bigint Number of the message when transfer‐
ring the batch data. A server prefix can
have multiple messages with the same
MsgNo.
MsgCounter Bigint Sequential ID of the message gener‐
ated by the PCS 7 OS.
*: (comment.ROOTGUID = executedesig.ROOTGUID, comment.POBJID=
executedesig.POBJID, comment.POTID= executedesig.POTID, comment.P2OBJID=
executedesig.P2OBJID, comment.P2OTID= executedesig.P2OTID, comment.EsigDynDataId
= executedesig.EsigDynDataId)
3.10 vContainer
Container
This view shows the available containers. It is a specialization of the vRecipeElement view.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch, master rec‐
ipe or library)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
POBJID Int ID of the higher-level object
POTID (Page 60) Int Type ID of the higher-level object
ParentActivationCounter Int Run of the parent of the object
OBJID Int ID of the object
OTID (Page 60) Int Type ID of the object
ActivationCounter Int Run of the object
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
State (Page 62) Int Status of the container
ExState (Page 63) Int Expanded status of the container
Start datetimeoffset(3) Start time of the container
End datetimeoffset(3) End time of the container
DurationPlanned Int Planned duration in seconds
DurationActual Int Actual duration in seconds
MonitoringTime Int Monitoring time in seconds
OverwriteDuration Int Runtime exceeded
ScaleFunc (Page 64) Int Scaling the runtime
Description of the views
3.10 vContainer
SIMATIC BATCH - Views of the report data V9.0
18 Programming Manual, 05/2017, A5E38208785-AA
