Name Data type Description
Description nvarchar(max) Description of the object
StepNbr Int Number of the object (contid*10000+ter‐
mid)
State (Page 62) Int Status of the container
ExState (Page 63) Int Expanded status of the container
Start datetimeoffset(3) Start time of the container
End datetimeoffset(3) End time of the container
DurationPlanned Int Planned duration in seconds
DurationActual Int Actual duration in seconds
MonitoringTime Int Monitoring time of the object in seconds
OverwriteDuration Int Runtime calculated by the system. Can
be changed or overwritten.
ScaleFunc (Page 64) Int Modification of the duration
ExecuteInPLC Int Executed in AS-based mode
GraphicType tinyint Type of stored graphic (1:png)
Graphic varbinary(max) Graphic in BLOB format
3.40 vProcedure
Recipes
This view shows the existing recipes (master recipes (OTID = 125), libraries (OTID = 126),
and control recipes (OTID = 127)). The root object is the object itself, if it is a master recipe or
a library. In the case of a control recipe, the batch corresponds to the root object.
Definition
Name Data type Description
OGUID Uniqueidentifier GUID of the object
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type ID of the root object
OBJID Int ID of the object
OTID Int Type ID of the object
Name nvarchar(255) Name of the object
Description nvarchar(max) Description of the object
Model Int Recipe model (2:Flat, 1:Hierarchical)
Version nvarchar(255) Version of the object
State (Page 59) Int Status of the procedure
ExState (Page 64) Int Extended status of the procedure
Start datetimeoffset(3) Start time of the container
End datetimeoffset(3) End time of the container
DurationPlanned Int Planned duration in seconds
Description of the views
3.40 vProcedure
SIMATIC BATCH - Views of the report data V9.0
42 Programming Manual, 05/2017, A5E38208785-AA
