3.12 vDataType
Data types
View of all data types of the process cell.
Definition
Name Data type Description
PCellGUID Unique identifier GUI of the process cell object
PCellPartID Int Part ID of the process cell object
OBJID Int ID of the data type
Name nvarchar(255) Name of the data type
Description nvarchar(max) Description of the data type
3.13 vDataTypeValue
Values of the enumeration data types
View of all values of the enumeration data types from the vDataType view.
Definition
Name Data type Description
PCellGUID Unique identifier GUI of the process cell object
PCellPartID Int Part ID of the process cell object
POBJID Int ID of the container object (DataTypeID)
OBJID Int ID of the Enum value
Name nvarchar(255) Name of the Enum value
Description nvarchar(max) Description of the Enum value
3.14 vExecutedEsigs
Executed signatures
This is a simplified view of the electronic signatures that have been executed. Columns POBJID
and P2OBJID correspond to the address of the object, where the signature has been entered.
ExecutedEsigs → Recipe element (P) → Parent object of the recipe element (P2)
Description of the views
3.12 vDataType
SIMATIC BATCH - Views of the report data V9.0
20 Programming Manual, 05/2017, A5E38208785-AA
