Name Data type Description
ROOTOTID (Page 60) Int Type ID of the root object
OBJID Int ID of the candidate
OTID (Page 60) Int Type ID of the candidate
POBJID Int ID of the allocation
POTID (Page 60) Int Type ID of the allocation
InstanceId Int ID of unit
3.4 vBatch
Batches
This view shows the available batches.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (order)
ROOTOBJID Int ID of the root object
ROOTOTID (Page 60) Int Type of the root object
OGUID Uniqueidentifier GUID of the object
OBJID Int ID of the object
OTID (Page 60) Int Type of the object
Name nvarchar(255) Name of the batch
Description nvarchar(max) Batch description
Quantity Float Planned quantity
ActQuantity Float Current quantity of the product
FormulaCategoryName nvarchar(255) Name of the formula category
FormulaName nvarchar(255) Name of the formula
FormulaVersion nvarchar(255) Version of the formula
FormulaGUID Uniqueidentifier GUID of the formula
FormulaID Int ID of the formula
MRecipeName nvarchar(255) Name of the master recipe
MRecipeVersion nvarchar(255) Version of the master recipe
MRecipeGUID Uniqueidentifier GUID of the master recipe
MRecipeId Int ID of the formula
ProductName nvarchar(256) Name of the product
ProductCode nvarchar(256) Code of the product
ProudctGUID Uniqueidentifier GUID of the product
UoMId Int ID of the physical unit
PlanStart datetimeoffset(3) Planned start time for the batch
PlanEnd datetimeoffset(3) Planned end time for the batch
Description of the views
3.4 vBatch
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 13
