Name Data type Description
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
PrameterId Int ID of the associated parameters (vPar‐
ameterDescription view)
AllocId Int ID of the allocation
CategoryId Int ID of the unit type or of the block type
(view: vCategory)
3.28 vOnlineConditions
Conditions of the transitions in batches
This view contains the transition conditions of batches. Only the conditions of objects already
started are shown here.
Definition
Name Data type Description
ROOTGUID Uniqueidentifier GUID of the root object (batch)
ROOTOTID (Page 60) Int Type ID of the root object
ROOTOBJID Int ID of the root object
P2OBJID Int ID of the higher-level object of the con‐
tainer object
P2OTID (Page 60) Int ID of the higher-level object of the con‐
tainer object
POBJID Int ID of the container object
POTID (Page 60) Int Type ID of the container object
ActivationCounter Int Run of the transition
OBJID Int ID of the condition
DataID Bigint Unique ID of the notification for the con‐
dition set to which this condition belongs.
gate_result Int Result of the transition
cond_result Int Result of the condition
Operator nvarchar(8) Operator of the condition
left_operand nvarchar(255) Left operand
left_datatyp nvarchar(255) Data type ID of the left operand
left_UoMName nvarchar(255) Unit of measure of the left operand
left_value nvarchar(255) Value of the left operand
right_operand nvarchar(255) Right operand
right_datatype nvarchar(255) Data type ID of the right operand
right_UoMName nvarchar(255) Unit of measure of the right operand
right_value nvarchar(255) Value of the right operand
Description of the views
3.28 vOnlineConditions
SIMATIC BATCH - Views of the report data V9.0
Programming Manual, 05/2017, A5E38208785-AA 31
