Siemens Simatic S7-300

Representation of the analog values of analog modules
5.1 Representation of the analog values of analog input channels
S7-300 Automation System Module data
5-10 Manual, 08/2006, A5E00105505-04
Representation of the analog values of Ni 100 GOST Klima resistance thermometers
Table 5-17 Representation of the analog values of Ni 100 GOST Klima resistance thermometers
Units Units
Ni 100
GOST
Klima in °C
(1 digit =
0.1°C)
dec hexa-
decimal
Ni 100
GOST
Klima in °F
(1 digit =
0.1 °F)
dec hexa-
decimal
Range
> 212.40 32767 7FFF
H
> 414.30 32767 7FFF
H
Overflow
212.40
:
180.1
2124
:
1801
084C
H
:
0709
H
414.30
:
356.10
41430
:
35610
A1D6
H
:
8B1A
H
Overshoot range
180.0
:
-60.0
1800
:
-600
0708
H
:
FDA8
H
356.00
:
-76.00
35600
:
-7600
8B10
H
:
E250
H
Nominal range
-60.1
:
-105.0
-601
:
-1050
FDA7
H
:
FBE6
H
-76.10
:
-157.00
-7610
:
-15700
E246
H
:
C2AC
H
Undershoot range
< - 105.0 -32768 8000
H
< - 157.00 -32768 8000
H
Underflow
Representation of the analog values of Cu 10 Standard resistance thermometers
Table 5-18 Representation of the analog values of Cu 10 resistance thermometers
Units Units Units Cu 10
Standard in
°C (1 digit =
0.01°C)
dec hexa-
decimal
Cu 10
Standard in
°F (1 digit =
0.01 °F)
dec hexa-
decimal
Cu 10
Standard in
K (1 digit =
0.01 K)
dec hexa-
decimal
Range
> 312.0 32767 7FFF
H
> 593.6 32767 7FFF
H
> 585.2 32767 7FFF
H
Overflow
312.0
:
260.1
3120
:
2601
C30
H
:
A29
H
593.6
:
500.1
5936
:
5001
1730
H
:
12D5
H
585.2
:
533.3
5852
:
5333
16DC
H
:
14D5
H
Overshoot
range
260.0
:
-200.0
2600
:
-2000
A28
H
:
F830
H
500.0
:
-328.0
5000
:
-3280
1389
H
:
F330
H
533.2
:
73.2
5332
:
732
14D4
H
:
2DC
H
Nominal
range
-200.1
:
-240.0
-2001
:
-2400
F82F
H
:
F6A0
H
-328.1
:
-400.0
-3281
:
-4000
F32F
H
:
F060
H
73.1
:
33.2
731
:
332
2DB
H
:
14C
H
Underflow
range
< - 240.0 -32768 8000
H
< - 400.0 -32768 8000
H
< 33.2 32768 8000
H
Underflow
