Parameter sets of signal modules
A.9 Parameters of analog output modules
S7-300 Automation System Module data
A-36 Manual, 08/2006, A5E00105505-04
A.9 A.9 Parameters of analog output modules
Parameters
The table below lists all parameters you can set for analog output modules. The comparison
shows:
● which parameters you can edit in
STEP 7 , and
● which parameters you can change using SFC 55 "WR_PARM".
Parameters set in
STEP 7 can also be transferred to the module using SFC 56 and SFC 57.
Table A-28 Parameters of analog output modules
Programmable, using ...
Parameters Data record
number
... SFC 55 ... PG
Diagnostics: Group diagnostics 0 No Yes
Diagnostics interrupt enable Yes Yes
Reaction to CPU STOP Yes Yes
Output type Yes Yes
Output range Yes Yes
Substitution value
1
Yes Yes
Note
To enable diagnostic interrupts in the user program at data record 1, you first need to enable
diagnostics at data record 0 in
STEP 7 .
