3.18 Digital output module SM 322; DO 32 x 120/230 VAC/1 A; (6ES7322-1FL00-0AA0)
S7-300 Automation System Module data
3-50 Manual, 08/2006, A5E00105505-04
Technical data
Output delay (resistive load)
• at "1" to "0"
max. 100 μs
• at "1" to "0"
max. 500 μs
Load resistance range 48 Ω to 4 kΩ
Lamp load max. 5 W
Wiring two outputs in parallel
• for redundant load control
supported (only outputs of the same group)
• for performance increase
not supported
Control of a digital input supported
Switching frequency
• with resistive load
max. 100 Hz
• with inductive load to IEC 947-5-1, DC 13
max. 0.5 Hz
• with lamp load
max. 10 Hz
Internal limiting of the inductive shutdown voltage to typ. L + (-53 V)
Short circuit-proof output Yes, electronic
• Threshold
typ. 1 A
Wiring the actuators with 40-pin front connector
3.18 3.18 Digital output module SM 322; DO 32 x 120/230 VAC/1 A;
(6ES7322-1FL00-0AA0)
Order number
6ES7322-1FL00-0AA0
Properties
Properties of SM 322; DO 32 x AC 120/230 V/1 A:
● 32 outputs, fused and electrically isolated in groups of 8
● Output current 1.0 A
● Rated load voltage 120/230 VAC
● Blown fuse indicator for each group
● Suitable for AC solenoids, contactors, starters, FHP motors and signal lamps
● Group error display (SF)
