Dimensional drawings
C.2 Dimensional drawings of the power supply modules
S7-300 Automation System Module data
C-8 Manual, 08/2006, A5E00105505-04
C.2 C.2 Dimensional drawings of the power supply modules
PS 307; 2 A
The figure below shows the dimensional drawing of the PS 307; 2 A power supply module.
Figure C-10 Power supply module PS 307; 2 A
PS 307; 5A
The figure below shows the dimensional drawing of the PS 307; 5 A power supply module.
Figure C-11 Power supply module PS 307; 5 A
