Siemens Simatic S7-300

Digital modules
3.24 Digital output module SM 322; DO 8 x DC 24 V/ 0.5 A; with diagnostics interrupt; (6ES7322-8BF00-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
3-77
3.24.1 Parameters of SM 322; DO 8 x DC 24 V/0.5 A
Programming
The general procedure of programming digital modules is described in the chapter
Programming digital modules.
Parameters of SM 322; DO 8 x DC 24 V/0.5 A
The table below lists the configurable parameters of SM 322; DO 8 x DC 24 V/0.5 A,
including defaults.
The defaults apply if you have not set any parameters in STEP 7.
Table 3-18 Parameters of SM 322; DO 8 x DC 24 V/0.5 A
Parameters Range of values Default Parameter
type
Scope
Enable
• Diagnostic interrupt
Yes/no No
Reaction to CPU STOP Set substitution value (SSV)
Hold last value (HLV)
SSV
Dynamic Module
Diagnostics
• Wirebreak
• Load voltage L+ missing
• Short-circuit to M
• Short-circuit to L+
Yes/no
yes/no
yes/no
Yes/no
No
No
No
No
Static
Channel
Set substitution value "1" Yes/no No Dynamic Channel
