Parameter sets of signal modules
A.11 Parameters of analog IO modules
S7-300 Automation System Module data
A-42 Manual, 08/2006, A5E00105505-04
Measuring methods and ranges
The table below lists all measuring methods/ranges of analog IO modules, including their
codes. Enter these codes at bytes 2 to 5 in data record 1 (refer to the previous figure.)
Table A-33 Measuring range codes of analog IO modules
Measuring method Code Measuring range Code
disabled 2#0000 disabled 2#0000
Voltage 2#0001 0 V to 10 V 2#1000
Resistance (4-wire connection) 2#0100 10 kΩ 2#1001
Thermal resistance + linearization 4-wire connection 2#1000 Pt 100 Klima 2#0000
Output types and output ranges
The table below lists all output types/ranges of analog IO modules, including their codes.
Enter these codes at bytes 6 and 7 of data record 1 (refer to the previous figure.)
Table A-34 Output range codes of analog IO modules
Output type Code Output range Code
disabled 2#0000 disabled 2#0000
Voltage 2#0001 0 V to 10 V 2#1000
