6.10 Analog input module SM 331; AI 8 x TC; (6ES7331-7PF11-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-91
Technical data
Integration/conversion time/resolution (per channel)
• programmable
• Basic conversion time in ms
Yes
3.3 ms *****
• additional conversion time for wire-break monitoring in ms
93 *
• Resolution (including overshoot range)
• Noise suppression at interference frequency f1 in Hz
16 bits (including sign)
400/60/50
Measured value smoothing None / low/ average/ high
Basic execution time of the module (all channels enabled) 10 ms
Noise suppression, error limits
Noise suppression at f = n (f1 1%), (f1 = interference frequency) n = 1.2, etc.
• Common-mode interference (U
CM
< 60 V AC)
• Series mode interference (peak value of disturbance <
rated input range)
> 100 dB
> 90 dB **
Crosstalk between inputs > 100 dB
Operational limit (across temperature range, relative to 0 °C to 60 °C input range). Note: This limit does not cover the cold
junction error
3)
.
• Thermocouple
-200 °C to +400 °C ± 0.7 °C Type T
-230 °C to -200 °C ± 1.5 °C
-150 °C to +600 °C ± 0.9 °C Type U
-200 °C to -150 °C ± 1.2 °C
-200 °C to +1000 °C ± 1.2 °C Type E
-230 °C to -200 °C ± 1.5 °C
-150 °C to +1200 °C ± 1.4 °C Type J
-210 °C to -150 °C ± 1.7 °C
-150 °C to +900 °C ± 1.5 °C Type L
-200 °C to -150 °C ± 1.8 °C
-150 °C to +1372 °C ± 2.1 °C Type K
-220 °C to -150 °C ± 2.9 °C
-150 °C to +1300 °C ± 2.2 °C Type N
-220 °C to -150 °C ± 3.0 °C
+100 °C to +1769 °C ± 1.5 °C Type R
-50 °C to +100 °C ± 1.8 °C
+100 °C to +1769 °C ± 1.7 °C Type S
-50 °C to +100 °C ± 2.0 °C
+800 °C to +1820 °C ± 2.3 °C Type B ****
+200 °C +800 °C ± 2.5 °C
+100 °C to +2315 °C ± 2.3 °C Type C
0 °C +100 °C ± 2.5 °C
Txk/xk(L) -200 ° C -150 ° C ± 1.5 °C
