6.12 Analog output module SM 332; AO 4 x 16 bit; isochronous; (6ES7332-7ND02-0AB0)
S7-300 Automation System Module data
Manual, 08/2006, A5E00105505-04
6-111
Technical data
Settling time
• with resistive load
• with capacitive load
• with inductive load
0.2 ms
3.3 ms
0.5 ms (1 mH) / 3.3 ms (10 mH)
Noise suppression, error limits
Crosstalk between outputs > 100 dB
Operational limit (across the temperature range, relative to output range)
• Voltage output
• Current output
±0,12%
±0,18%
Basic error limit (operational error limit at 25°, relative to output range)
• Voltage output
± 10 V
0 V to 10 V
1 V to 5 V
±0,02%
±0,02%
±0,04%
• Current output
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
±0,02%
±0,02%
±0,04%
Temperature error (relative to output range)
• Voltage output
• Current output
± 0.0025%/K
± 0.004%/K
Linearity error (relative to output range) ±0,004%
Repeat accuracy (in transient state at 25 °C, relative to output range) ±0,002 %
Output ripple; range 0 Hz to 50 kHz (relative to output range) ±0,05 %
Status, interrupts, diagnostics
Interrupts
• Diagnostic interrupt
programmable
Diagnostics functions
• Group error display
• Reading diagnostics information
programmable
red LED (SF)
supported
Injection of substitution values Yes, programmable
Actuator selection data
Output ranges (rated values)
• Voltage
± 10 V
0 V to 10 V
1 V to 5 V
• Current
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
Load impedance (in the rated range of the output)
• For voltage outputs
– capacitive load
min. 1 kΩ
max. 1 µF
• For current outputs
– inductive load
max. 500 Ω
max. 1 mH
